ZT-D5289-D Brushed DC Motor
ZT-D5289-D brushed dc motor with verified 12V/24V options and 4000–8000 rpm source-listed no-load speed versions.
12V / 24V
- Voltage options: 12V / 24V
- Rated speed options: 3000 / 6000 rpm
Product Detail
ZT-D5289-D is a brushed dc motor with source-listed 12V and 24V options. Its performance table preserves 2 voltage/speed configurations and keeps every source-provided value aligned to its original row.
Key Features
- 12V and 24V source-listed voltage options
- 2 source-listed no-load speed versions from 4000 to 8000 rpm
Specifications
- Model: ZT-D5289-D
- Product type: Brushed DC Motor
- Voltage options: 12V / 24V
- Rated speed options: 3000 / 6000 rpm
Technical Sheet
| Voltage | No-load speed (rpm) | Rated speed (rpm) | Rated torque (g·cm) | Stall torque (g·cm) | Rated current (mA) | Stall current (mA) |
|---|---|---|---|---|---|---|
| 12V | 4000 | 3000 | 1000 | 3000 | 1825 | 6735 |
| 24V | 8000 | 6000 | 1800 | 5400 | 2000 | 8000 |
Product Pictures
FAQ
What voltage options are listed for ZT-D5289-D?
The structured specification table lists 12V and 24V options.
What no-load speed versions are available?
The source table lists 4000, 8000 rpm no-load speed versions.
